19”’ | Hand Wind | Swiss Lever | Small Seconds | Alarm |

Remarks:

• Two barrels, one dedicated to alarm
  • Turning the crown to the left winds the movement
  • Turning the crown to the right winds the alarm mainspring
• Alarm with hammer on bell spring
• Set time: push pin at 11H and turn crown
• Set alarm time: push pin at 1H and turn crown
• Le Phare first produced this movement. The company was taken over by Zenith in 1915
• The movement is also available with a diameter of 18”’
• The movement shown is missing the winding pinion

• Listing ID: 19029
• Manufacturer / Brand: Zenith / Le Phare
• Caliber: Réveil 19'''
• Size in French Lignes: 19'''
• Size range mm largest diameter: > 40 mm
• Shape: Round
• Winding: Manual (Crown)
• Hands Setting: Crown with pin/pusher
• Seconds Hand: Small seconds
• Escapement: Lever (Swiss, English, Glashütte)
• Date, Day, Month...: None
• Other Functions: Alarm
• Jewels: 15
• Setting Lever Screw/Pin Position: Left
• Balance Position: Bottom (120 - 240°)
• Shock Protection: None
• Beats per hour: 18,000
• Balance Type: Bimetallic screw balance with Breguet hairspring
• Power Reserve: Approx. 1 day
• Production Period: Around 1920
• Country: Switzerland
• Identification: Shown in the Zenith book from Manfred Rössler. Some movements marked with Zenith.
• Contributor ©: Uhrforum.de member Badener (Andreas Kelz)
• External Link 2: https://forumamontres.forumactif.com/t264026-quelques-remarques-sur-la-montre-reveil-de-zenith
