19”’ | Hand Wind | Swiss Lever | Small Seconds |

Remarks:

• Pillar construction
• Indirect minute
• Impulse pin not made of ruby, but metal
• This movement is a Lépine (open face) movement. There is also a Savonnette (hunter) version as Malleray Model No. 6

• Listing ID: 18218
• Manufacturer / Brand: Malleray
• Caliber: Model No. 5
• Size in French Lignes: 19'''
• Size range mm largest diameter: > 40 mm
• Shape: Round
• Winding: Manual (Crown)
• Hands Setting: Crown
• Seconds Hand: Small seconds
• Escapement: Lever (Swiss, English, Glashütte)
• Date, Day, Month...: None
• Jewels: 15
• Setting Lever Screw/Pin Position: Left
• Balance Position: Left (240 - 360°)
• Holes in setting lever spring or rocking bar: 0 = no setting lever spring and no rocking bar
• Shock Protection: None
• Beats per hour: 18,000
• Balance Type: Monometallic screw balance
• Power Reserve: Unknown
• Production Period: Probably around 1909
• Country: Switzerland
• Identification: Registered by Malleray in the Swiss Official Gazette of Commerce on 03.08.1909 as model No. 5. Model No. 5 is not an official caliber designation, but was used to register the design.
• Contributor ©: Uhrforum.de member Badener (Andreas Kelz)
